2" Exit High Frequency Compression Driver

D4400Ti

In stock

2″ Highs Driver
Titanium Diaphragm
110 dB – 400 Watts

$129.91

In stock

PRICE FOR SINGLE UNIT

SKU: D4400Ti Category: HF Drivers & Horns Tags: COMPRESSION DRIVER, TITANIUM

Features

The D4400Ti 2” exit Titanium High Frequency Driver is the latest improved version of our D4260Ti. The new improved magnet and plates design result in more energy into the gap, higher sensitivity, lower distortion and better overall performance. These modifications combined result in better control diaphragm displacement and deformation.

The D4400Ti is designed to ensure a quality sound and long lasting play in your large environment applications.

Highlights

Throat Diameter: 2″
Type: Bolt-On
Nominal Impedance: 8 Ohms
Rated AES Power Handling (RMS): 200 Watts
Program Power: 400 Watts

Technical Details

GENERAL SPECIFICATIONS

Exit Throat Diameter	2” (50 mm)
Nominal impedance	8 Ohms
Rated AES Power Handling (RMS)	200 Watts
Program Power	400 Watts
Sensitivity 2.83V at 1m	110 dB
Recommended Hi Pass Crossover For Full Power Handling	1600 Hz 12db Per Octave Crossover
Frequency Response at -10dB	1,000 – 17,000 Hz
Voice Coil Diameter	4”(101.6 mm)
Voice Coil Wire	CCAW
Voice Coil Former Material	Kapton
Diaphragm Material	Titanium
Flux Density	1.85 T
Magnet Material	Ferrite

EXTRA INFO

Overall Diameter	7.86” (199.75 mm)
Overall Depth	3.18” (81 mm)
Mounting Bolt Circle	M6x4 4” (101.6 mm)
Net Weight	19.20 lbs (8.70 kg)
Shipping Weight	21.16 lbs (9.60 kg)
Carton Dimensions W x L x H	8.66” x 8.66” x 4.60” (220 x 220 x 117 mm)
