10MR1000 PRO
-
- 10″ Midrange – 8 Ohm
- Ferrite Magnet
- 100 dB – 1000 Watts
$169.91
In stock
PRICE FOR SINGLE UNIT
Features
Features
The 10MR1000 PRO is a high power, and high output midrange from our PRO Series primarily designed to perform in small sealed, horn loaded and vented enclosures, making it the perfect choice for a variety of installations, including professional sound reinforcement, live sound, home audio speakers with high outputs, as well as high SPL car audio.
- Excellent performance in 3-way systems, with high detailed percussion instruments tones at a high sensitivity of 100 dB
- Premium paper cone and cloth surround for high clarity, smooth response, and linear excursion at high 1000 Watts RMS program power.
- 3” Inside/outside wound copper voice coil on glass fiber former lend solid power handling capability
- Under spider and rear periphery venting allows cool running voice coil on long-lasting playing sessions.
- Low Qts means high damping and excellent performance in smaller boxes.
This professional midrange loudspeaker delivers smooth, clear vocals that will impress any listener! Its high efficiency makes it easy to power, all thanks to a specially light weight cone designed to deliver smooth vocals and well define midbass tones.
Cast aluminum frame adds structural integrity, while a paper/glass fiber cone attached to a large 3″ voice coil keeps everything under control at high level outputs, making an easy transition to a high frequency driver.
PRV 10″ Midrange Speaker 10MR1000 PRO 1000 Watts / 8 Ohm High Power and Output PRO Audio Loudspeaker
Technical Details
GENERAL SPECIFICATIONS
| Nominal Diameter | 10″ (254 mm) |
| Nominal impedance | 8 Ohm |
| Nominal Power Handling* | 500 Watts |
| Continuous Program Power (RMS)** | 1000 Watts |
| Max Peak Power*** | 2000 Watts |
| Sensitivity 2.83V at 1m | 100 dB |
| Recommended Hi Pass Crossover For Full Power Handling | 150 Hz 12db Per Octave Crossover |
| Frequency Response | 75 – 6,000 Hz |
| Voice Coil Diameter | 3″ (75 mm) |
| Voice Coil Wire | Copper |
| Voice Coil Winding Depth | 9.2 mm |
| Former Material | Glass Fiber |
| Magnetic Gap Depth | 8.0 mm |
| Frame Material | Die cast Aluminum |
THIELE-SMALL PARAMETERS
| Equivalent Volume | Vas | 26.1 l |
| Excursion (mathematical)*** | Xmax | 2.60 mm |
| Free Air Resonance | Fs | 73.20 Hz |
| Mechanical Factor | Qms | 7.94 |
| Electrical Factor | Qes | 0.28 |
| Total Factor | Qts | 0.27 |
| Cone Area | Sd | 391 cm² |
| Mechanical Mass | Mms | 32.94 g |
| Bl Factor | Bl | 17.90 Tm |
| Dc Resistance | Re | 5.0 Ohm |
| Inductance | Le | 0.48 mH at 1 kHz |
| Mechanical Mass Without Air | Mmd | 34.26 g |
| Mechanical Compliance | Cms | 0.122 mm/N |
***Xmax=(Voice coil winding depth-Magnetic Gap depth)/2+ Magnetic Gap Depth/4
EXTRA INFO
| Overall Diameter | 10.23″ (260 mm) |
| Front Mount Baffle Cutout | 9.13″ (232 mm) |
| Mounting Depth | 4.31″ (109.5 mm) |
| Overall Depth | 4.86″ (123.5 mm) |
| Net Weight | 15.65 Lbs (7.1 kg) |
| Shipping Weight | 16.75 Lbs (7.6 kg) |
| Carton Dimensions W x L x H | 11.42″ x 11.42″ x 5.90″ (290 x 290 x 150 mm) |
Repair Parts
Recone Kit for 10MR1000 PRO
