8MB500
-
- 8″ Midbass – 8 Ohm
- Ferrite Magnet
- 95 dB – 500 Watts
$39.91
In stock
PRICE FOR SINGLE UNIT
Features
Features
The 8MB500 was designed to provide outstanding durability and strong midbass punch. This 8″ professional loudspeaker midbass is purpose-built to cover the critical low frequency range in a home speaker setup, but also works great as a door speaker in car audio applications.
- A deep and punchy midbass response along with a strong vocal response
- PRO audio midbass woofer offers smooth lower response through a punchy mid bass range
- Natural paper cone and cloth triple roll surround for smooth response
- Handles 500 Watts, guaranteeing endurance at loudest volumes
- Impressive choice for high output home, car, and professional audio systems – 8 Ohm impedance
Built with premium components to ensure absolute high sound fidelity, one of which is its compact push terminals, which connect to its silver tinsel lead wires attached to its high temperature CCAW voice coil.
Featuring the latest technology we can increase tremendously the magnet field without huge magnet, making this midbass one of a kind, with large diameter motor, not bulky yet capable of handling high power!
Featuring a naturally damp paper cone and special coated dust cap, makes this professional speaker able to cover a wide range of frequencies from 75 Hz to 7,500 Hz in three-way systems.
Developed to perform well in tight enclosures, its triple roll surround keeps its cone travel linear at high mibdass excursion. The right combination of cone and suspension gives this speaker an excellent human vocal reproduction with dynamic midbass sound.
PRV 8″ Midbass Speaker 8MB500 PRO Audio 500 Watts / 8 Ohm
Technical Details
GENERAL SPECIFICATIONS
| Nominal Diameter | 8″ (203 mm) |
| Nominal impedance | 8 Ohm |
| Nominal Power Handling | 250 Watts |
| Continuous Program Power (RMS) | 500 Watts |
| Max Peak Power | 1000 Watts |
| Sensitivity 2.83V at 1m | 95 dB |
| Recommended Hi Pass Crossover** **For Full Power Handling | 95Hz** **12db Per Octave Crossover |
| Frequency Response at -10DB | 75 – 7,500 Hz |
| Voice Coil Diameter | 2″ (50 mm) |
| Voice Coil Wire | CCAW |
| Voice Coil Winding Depth | 12.0 mm |
| Former Material | Kapton |
| Magnetic Gap Depth | 6.0 mm |
| Frame Material | Stamped Steel |
THIELE-SMALL PARAMETERS
| Equivalent Volume | Vas | 19.38 l |
| Excursion (mathematical)*** | Xmax | 4.50 mm |
| Free Air Resonance | Fs | 69.4 Hz |
| Mechanical Factor | Qms | 21.86 |
| Electrical Factor | Qes | 0.78 |
| Total Factor | Qts | 0.75 |
| Cone Area | Sd | 241 cm² |
| Mechanical Mass | Mms | 21.91 g |
| Bl Factor | Bl | 8.66 Tm |
| Dc Resistance | Re | 6.1 Ohm |
| Inductance | Le | 0.29 mH at 1 kHz |
| Mechanical Mass Without Air | Mmd | 18.80 g |
| Mechanical Compliance | Cms | 0.240 mm/N |
***Xmax=(Voice coil winding depth-Magnetic Gap depth)/2+ Mgnetic Gap Depth/4
EXTRA INFO
| Overall Diameter | 8.25″ (209.5 mm) |
| Front Mount Baffle Cutout | 7.17″ (182 mm) |
| Mounting Depth | 3.35″ (85 mm) |
| Overall Depth | 3.62″ (92 mm) |
| Net Weight | 5.55 Lbs (2.52 kg) |
| Shipping Weight | 6.15 Lbs (2.78 kg) |
| Carton Dimensions W x L x H | 9.84″ x 9.84″ x 4.33″ (250 x 250 x 110 mm) |
