MT10SW1000 D4

In stock

10″ Shallow Subwoofer
Waterproof
1000 Watts Dual 4 Ohm

$139.91

In stock

PRICE FOR SINGLE UNIT

SKU: MT10SW1000 D4 Categories: Car Subwoofers, Low Frequency Speakers, New Products Tag: MOTO Series

Features

PRV Audio is proud to present our MT10SW1000 D4 Subwoofer from the MOTO Series (MT), a high performance line dedicated to motorsport installations.

Designed for small enclosures, this subwoofer will work in motorcycle saddlebags, slingshot pods, or any other enclosure around 1 cubic foot in size. This sub is made from the best materials and components to withstand the elements, so you can enjoy the highest low frequency output while riding or sitting in an open parking lot.

Optimized for use in compact enclosures this subwoofer is ideal for motorcycle saddlebags
4 layer high-temperature copper voice coil capable of handling 1,000 watts RMS program power, which makes high acoustic output
High roll U surround is attached to the cone with dual stitching allowing a generous 14 mm of Xmax for deep bass reproduction without any issues.
Another Key premium components that ensure power handling, durability at high excursion are its large 7″ premium grade spider with weaved copper tinsel lead.
Side Forced Cooling System with vented back plate Design for Better Heat Dissipation
Dual 4 Ohm, Works well with Mini MDX2500.1 1 Ohm Connect two subs in parallel to 1 ohm

Its shallow profile takes up very little space inside any enclosure. This compact design will fit and sound great in any saddlebag that has about 1 cubic foot.

Recommended enclosure:

Compact Sealed Box: 0.9 cubic feet
Compact Ported Box: 1 cubic foot with a 3″ Diameter by 7″ Long Port Tube tuned at 45Hz
Optimal Ported Box: 1.25 cubic feet with a 3″ Diameter by 9″ Long Port Tube tuned at 37Hz

This subwoofer established the new benchmark for low frequency for outdoor applications, making it ideal for improving the sound system in your boat, UTV, 4-wheeler, Slingshot or motorcycle.

This 10-inch subwoofer delivers the kind of bass output you feel outdoors, not just vibrations. Also Available in 8 inch – MT8SW800 D4

PRV 10” Motorsports Subwoofer MT10SW1000 Dual 4 Ohm 1000 Watts Shallow Sub for Motorcycle Slingshot Waterproof

Technical Details

GENERAL SPECIFICATIONS

Nominal Diameter	10″ (254 mm)
Nominal impedance	4 + 4 Ohm
Nominal Power Handling	500 Watts
Continuous Program Power (RMS)	1000 Watts
Max Peak Power	2000 Watts
Sensitivity 1.41V at 1m	86 dB (Parallel VC)
Voice Coil Diameter	2.0″ (50 mm)
Voice Coil Wire	Copper
Voice Coil Winding Depth	33.0 mm
Former Material	Black Aluminum
Magnetic Gap Depth	10 mm
Frame Material	Die Cast Aluminum

^{*Nominal power handling is defined as the maximum RMS power that the speaker can handle in a
2-hour test with a pink noise with 6dB of crest factor and a bandpass filter with 12db/oct tuned in its usable
frequency range.} ^{**Continuous Program Power (RMS) is the maximum power that the speaker can handle considering
a regular musical program using our recommended filters, this power can be used to define the optimum amplifier
power to provide a clean signal without clipping or saturation.} ^{***Max Peak Power is the maximum power operation for the speaker, this power is allowed just
for a few fractions of a second, usually found just on the peaks of the music. Keeping this power for a little
longer timer will damage the speaker.}

THIELE-SMALL PARAMETERS

Equivalent Volume	Vas	29.9 l
Excursion (mathematical)***	Xmax	14.00 mm
Free Air Resonance	Fs	36.2 Hz
Mechanical Factor	Qms	7.01
Electrical Factor	Qes	0.55
Total Factor	Qts	0.51
Cone Area	Sd	391 cm²
Mechanical Mass	Mms	140.9 g
Bl Factor	Bl	9.91 Tm
Dc Resistance (Parallel VC)	Re	1.7 Ohm
Inductance	Le	1.17 mH at 1 kHz
Mechanical Mass Without Air	Mmd	136.4 g
Mechanical Compliance	Cms	0.137 mm/N

***Xmax=(Voice coil winding depth-Magnetic Gap depth)/2+ Mgnetic Gap Depth/4

EXTRA INFO

Overall Diameter	10.38″ (263.7 mm)
Front Mount Baffle Cutout	9.37″ (238 mm)
Mounting Depth	4.55″ (115.5 mm)
Overall Depth	5.53″ (140.5 mm)
Net Weight	12.01 Lbs (5.45 kg)
Shipping Weight	14.13 Lbs (6.5 kg)
Carton Dimensions W x L x H	11.6″ x 11.6″ x 7.1″ (295 x 295 x 180 mm)
