NEW!
1 Channel Full Range Amplifier

QS5000 2 Ohm

Out of stock

-

  • Full Range Amp
  • 1 Channel
  • 5000 Watts 2Ω

$389.91

Out of stock

PRICE FOR SINGLE UNIT

Join the waitlist to be emailed when this product becomes available

SKU: QS5000 2 Ohm Categories: , Tag:

Features

Features

The QS Series amplifiers are designed for mids and highs applications, to power high power stuntwalls, custom door panels or any large system that requires clearer, louder sound for PRO Audio loudspeakers.

The QS5000 features a regulated power supply that is able to constantly deliver power and provides an unsurpassed efficiency rate of 80–90% in a small aluminum heatsink.

Looking for a bass amplifier? You may want to consider the RS Series if you need a SPL bass amplifier that delivers a constant deep bass response.


QS5000 2Ω
  • UNMATCHED PERFORMANCE: Digital Class D Brazilian Technology, 5000 watts TRUE RMS certified at full range output, provides outstanding results for demo car audio systems.
  • 1 Channel car audio amplifier stable at 2 Ohm gives you the benefit of wiring multiple speakers and dividing the power.
  • HIGH EFFICIENCY: Engineered to be the most efficient full range amplifier so that you can get the most out of your vehicle’s electrical system!
  • A small footprint and compact chassis make this amplifier easy to install anywhere in the vehicle: 12″ Wide x 10.25″ Length x 3.00″ Height
  • 4-way protection circuitry features high voltage, low voltage, shortage, and current protection. Built-in Power/Protection/Clip LED indicators on the top panel.
Channels 1 Channel
Rated RMS Power at 14.0 V at 2 Ohm 5000 Watts
Rated RMS Power at 14.0 V at 4 Ohm 3500 Watts

QS series

High Power Amplifier for your custom car audio system. The QS series brings the best Full Range HD Sound for clearer, louder sound for PRO Audio loudspeakers

QS5000 at 2 Ohm Stable, also available at 1 Ohm.

Its wide frequency response allows you to use it in many different applications, such as woofers, midbass, midrange, phenolic drivers, titanium drivers, among others. This amplifier is the perfect solution for large car audio systems.


QS5000 2Ω

Built-in HIGH and LOW pass filters allow the user to set the right frequency range for his equipment, from deep bass all the way to high frequencies.

Premium tiffany style RCA inputs ensure a more secure and tight connection, preventing any vibration problems.

This proprietary heat dissipation design will ensure a high air flow cooling fans controls its temperature to run cool on the most demanding playlists.


QS5000 2Ω

The LED indicator is a simple built-in tool that allows you to easily monitor the status of your amplifier while it is in use.

Its clipping indicator flashes at the limit of its maximum power output without any distortion, providing excellent sound performance while giving you the best value! All are protected by four-stage intelligent protection circuitry.


PRV Audio QS5000 2 Ohm Compact 1 Channel Car Audio Amplifier 5000 Watts RMS at 2 Ohm – Full Range Amp

Popular Installation configurations with this amplifier:



1 Channel Configuration for 8 Ohm Components

Its high power output channel allow you to install 4x 8 Ohm Speakers in parallel at 2 Ohm, giving up to 1250 watts per component..

QS5000-2-Ohm-Installation-Instructions-4x-8-Ohm
1 Channel Configuration for 4 Ohm components

Its high power output channel allow you to install 2x 4 Ohm Speakers in parallel at 2 Ohm, giving up to 2500 watts per component..

QS5000-2-Ohm-Installation-Instructions-2x-4-Ohm

Before Installing:

Before connecting your amplifier review all recommendations thoroughly, Any connection to the amplifier input or output must be performed only when the amplifier is OFF.

• The gauge of the power supply wiring is extremely important to reach the desired amplifier output and for the amplifier’s safety. Not using the recommended wire gauge will result in power loss and overheating of cables. It is important that the power supply cables are the shortest possible length. Always use 100% Copper cables and good quality connectors. This guarantees the sound’s quality and fidelity; To avoid damaging the cables, make sure that they do not touch sharp metal edges. Important: Use a fuse 12 inches away from the battery as a safety precaution

• Keep all cables as far away as possible from the ignition cables, electronic injection modules, and starter switch since they may cause noise interference

• In order to avoid interference, the signal cables ( RCA) must be kept away from the original wiring of the vehicle and from any other power supply cable.

• Amplifier must be installed in a solid and ventilated area. Do not mount amplifier to the back of a subwoofer box; excess vibration may cause damage to the amplifier.

The power rated data are based on equipment from the PRV Audio Group laboratory. Frequency reference of 100Hz to 1kHz with THD+N to ≤1 % in impedance referring to the indicated in each measurement. The electronic components and the manufacturing process can present manufacturing variations, thus leading to a variation in the measurements made. This amplifier is designed to perform on music applications (with speakers), any load test (resistant load) is not recommended.

PRV Audio products are guaranteed for a period of ONE (1) YEAR from the date of original purchase against any manufacturer’s defects in material and workmanship under normal use.

Technical Details

GENERAL SPECIFICATIONS

Impedance 2 Ohm
Channels 1 Channel
Rated RMS Power at 14.0 V at 2 Ohm 5000 Watts
Rated RMS Power at 14.0 V at 4 Ohms 3500 Watts
Average Efficiency 81%
Operating Voltage 9 to 16 Volts
Musical Current Draw 240 A
Minimum Power Wire Input (OFC) 0 Gauge
Protection Fuse or Circuit Breaker 250 Amps
Minimum Speaker Wire Output 14 Gauge
Frequency Response(-3dB) 20 – 15,000 Hz
Min. Input Sensitivity for Max. Output 200 mV
Signal Input 1 Pair RCA
Signal to Noise >90 dB
Protection System Low & High Supply Voltage / Shortage on Output / Low Impedance on Output
Heat Sink Type Heavy Duty Cast Aluminum
Dimensions ( W x D x H ) 12″ x 10.25″ x 3″
Weight 9.70 Lbs

The power rated data are based on equipment from the PRV Audio Group laboratory. Frequency reference of 60Hz to 1kHz with THD+N to ≤1 % in impedances referring to the indicated in each measurement. The electronic components and the manufacturing process can present manufacturing variations, thus leading to a variation in the measurements made. This amplifier is designed to perform on music applications (with speakers), any load test (resistant load) is not recommended.
