12" MIDRANGE LOUDSPEAKER
12MR2000X v2
-
- 12″ Mid Range – 8 Ohms
- Ferrite Magnet
- 100 dB – 2000 Watts
$189.91
Out of stock
PRICE FOR SINGLE UNIT
Features
Features
Coming Soon
Technical Details
GENERAL SPECIFICATIONS
| Nominal Diameter | 12″ (305 mm) |
| Nominal impedance | 8 Ohms |
| Rated AES Power Handling (RMS) | 1000 Watts |
| Program Power | 2000 Watts |
| Sensitivity 2.00V at 1m | 100 dB |
| Recommended Hi Pass Crossover** **For Full Power Handling | 180 Hz** **12db Per Octave Crossover |
| Frequency Response at -10dB | 100 – 5,300 Hz |
| Voice Coil Diameter | 4″ (65.5 mm) |
| Voice Coil Wire | CCAW |
| Voice Coil Winding Depth | 19.0 mm |
| Former Material | Kapton |
| Magnetic Gap Depth | 9.00 mm |
| Frame Material | Die cast aluminum |
THIELE-SMALL PARAMETERS
| Equivalent Volume | Vas | 30.9 l |
| Excursion (mathematical)*** | Xmax | 7.25 mm |
| Free Air Resonance | Fs | 75.9 Hz |
| Mechanical Factor | Qms | 11.18 |
| Electrical Factor | Qes | 0.45 |
| Total Factor | Qts | 0.43 |
| Cone Area | Sd | 568 cm² |
| Mechanical Mass | Mms | 64.13 g |
| Bl Factor | Bl | 19.7 Tm |
| Dc Resistance | Re | 5.7 Ohms |
| Inductance | Le | 0.35 mH at 1 kHz |
| Mechanical Mass Without Air | Mmd | 46.6 g |
| Mechanical Compliance | Cms | 0.068 mm/N |
***Xmax=(Voice coil winding depth-Magnetic Gap depth)/2+ Mgnetic Gap Depth/4
EXTRA INFO
| Overall Diameter | 12.40” (315 mm) |
| Front Mount Baffle Cutout | 11.14” (283 mm) |
| Mounting Depth | 4.72” (120 mm) |
| Overall Depth | 5.27” (134 mm) |
| Net Weight | 26.9 Lbs (12.2 kg) |
| Shipping Weight | 28.88 Lbs (13.1 kg) |
| Carton Dimensions W x L x H | 14.17” x 13.78” x 7.28” (360 x 355 x 185 mm) |
Repair Parts
Recone Kit for 12MR2000X v2 Loudspeaker
