15" PRO AUDIO WOOFER WEATHER RESISTANT

15W1000V2

In stock
  • 15″ Woofer – 8 Ohms
  • Ferrite Magnet
  • 97 dB – 1000 Watts

$89.99

In stock

PRICE FOR SINGLE UNIT

SKU: 15W1000V2 Category: Tag:

Features

The PRV Audio 15W1000 v2 woofer is designed with a reinforced cone and M-roll surround. It offers outstanding durability and high power handling. The cone is treated to be water resistant making it a perfect replacement for your weather beaten speakers and for use in outdoor applications.

The 15W1000-v2 offers a large 3” voice coil providing better cooling and rigidity, leading to increased life expectancy and accurate response. The cone was developed and tested with the necessary stiffness to withstand intense use while still offering a smooth, accurate sound.
The magnet assembly attached to a newly reinforced steel frame completes the 15W1000v2 to ensure a solid support structure, for long lasting play in almost most any environment.


Highlights

  • Nominal Impedance: 8 Ohms
  • Rated AES Power Handling (RMS): 500 Watts
  • Program Power: 1000 Watts
  • Sensitivity (1W/1m): 97 dB
  • Voice Coil Diameter: 3″

WARNING: Cancer and Reproductive Harm – www.p65warnings.ca.gov

Technical Details

GENERAL SPECIFICATIONS

Nominal Diameter 15″ (381 mm)
Nominal impedance 8 Ohms
Rated AES Power Handling (RMS) 500 Watts
Program Power 1000 Watts
Sensitivity 2.83V at 1m 97 dB
Recommended Hi Pass Crossover**
**For Full Power Handling
80 Hz**
**12db Per Octave Crossover
Frequency Response at -10dB 40 – 4,000 Hz
Voice Coil Diameter 3″ (76 mm)
Voice Coil Wire Copper
Voice Coil Winding Depth 16.5 mm
Former Material Aluminum
Magnetic Gap Depth 7.5 mm
Frame Material Stamped Steel




THIELE-SMALL PARAMETERS

Equivalent Volume Vas 206.1 l
Excursion (mathematical)*** Xmax 6.37 mm
Free Air Resonance Fs 39.56 Hz
Mechanical Factor Qms 25.9
Electrical Factor Qes 0.69
Total Factor Qts 0.68
Cone Area Sd 990 cm²
Mechanical Mass Mms 107.45 g
Bl Factor Bl 14.54 Tm
Dc Resistance Re 5.5 Ohms
Inductance Le 1.04 mH at 1 kHz
Mechanical Mass Without Air Mmd 89.82 g
Mechanical Compliance Cms 0.150 mm/N

***Xmax=(Voice coil winding depth-Magnetic Gap depth)/2+ Mgnetic Gap Depth/4


EXTRA INFO

Overall Diameter 15.20” (386 mm)
Front Mount Baffle Cutout 13.90” (353 mm)
Mounting Depth 5.82” (148 mm)
Overall Depth 6.18” (157 mm)
Net Weight 12.20 Lbs (5.53 kg)
Shipping Weight 13.74 Lbs (6.23 kg)
Carton Dimensions W x L x H 16.14” x 16.14” x 7.48”
(410 x 410 x 190 mm)



Customer questions & answers

  1. 0 votes
    Q What is the recommended enclosure volume and tuning for the 15w1000v2? answer now
    Asked by Darin Zunski on September 29, 2019 1:29 am
    Answered by the admin

    For this speaker (15W1000v2) our recommendation is a 105 liters vented box tuned at 56Hz (2 round-shaped ports with 100mm diameter and 70mm length)

    A high pass filter (HPF) is mandatory for high power tuned in 50Hz and 12db/Oct.

Send me a notification for each new answer.

Reviews

There are no reviews yet.

Be the first to review “15W1000V2”

Your email address will not be published. Required fields are marked *

Repair Parts

Recone Kit for 15W1000V2 Loudspeaker



Videos

PRV AUDIO 15W1000V2 Loudspeaker
