NEW!
6.5" SEALED BASKET MIDRANGE LOUDSPEAKER

6MR250SEAL

In stock

-

  • 6.5″ Midrange – 8 Ohm
  • Sealed Basket
  • 95 dB – 250 Watts

$34.91

In stock

PRICE FOR SINGLE UNIT

SKU: 6MR250SEAL Categories: ,

Features

Features

The 6MR250SEAL offers very smooth midrange response to the upper midrange up to 6 kHz. It is a perfect option as a seal basket speaker replacement in three-way cabinets.


  • Seal back basket simplifies cabinet manufacture, eliminating the need for a separate enclosure for other speakers.
  • Very compact model with only 2.20″ of mounting depth, suitable for use in 3-way cabinet systems ( Midbass + Seal Basket + High Frequency Driver or Tweeter).
  • Optimized to deliver detailed reproduction of mid-range frequencies from 400Hz to 6,000Hz.

A light paper cone is mated to a 1.5″ voice coil for great sensitivity and a 250 watts power handling. A durable spider suspension, woven cloth surround, and stamped steel frame are combined for durability over many hours of use.

Cabinet builders gravitate towards this driver for use in their systems when looking for a lightweight seal basket midrange.


Using a closed basket design in a speaker like the 6MR250SEAL offers several advantages. Firstly, it prevents interference from a woofer or midbass in a small Hi-Fi cabinet, resulting in a cleaner and more accurate midrange response.

Additionally, the closed basket design contributes to a smooth punch of midbass and midrange, enhancing the overall audio performance of the speaker.


PRV 6.5″ Midrange PRO Audio Speaker 6MR250SEAL Sealed Basket / 8 Ohm

Technical Details

GENERAL SPECIFICATIONS

Nominal Diameter 6″ (152 mm)
Nominal impedance 8 Ohm
Nominal Power Handling 125 Watts
Continuous Program Power (RMS) 250 Watts
Max Peak Power 500 Watts
Sensitivity 2.83V at 1m 95 dB
Recommended Hi Pass Crossover** **For Full Power Handling 400 Hz** **12db Per Octave Crossover
Frequency Response at -10DB 400 – 6,000 Hz
Voice Coil Diameter 1.5″ (38 mm)
Voice Coil Wire Copper
Voice Coil Winding Depth 8.0 mm
Former Material Kapton
Magnetic Gap Depth 6.0 mm
Frame Material Stamped Steel
*Nominal power handling is defined as the maximum RMS power that the speaker can handle in a 2-hour test with a pink noise with 6dB of crest factor and a bandpass filter with 12db/oct tuned in its usable frequency range. **Continuous Program Power (RMS) is the maximum power that the speaker can handle considering a regular musical program using our recommended filters, this power can be used to define the optimum amplifier power to avoid a clean signal without clipping or saturation. ***Max Peak Power is the maximum power operation for the speaker, this power is allowed just for a few fractions of a second, usually found just on the peaks of the music. Keeping this power for a little longer timer will damage the speaker.

THIELE-SMALL PARAMETERS

Equivalent Volume Vas 0.46 l
Excursion (mathematical)*** Xmax 2.50 mm
Free Air Resonance Fs 387.4 Hz
Mechanical Factor Qms 23.17
Electrical Factor Qes 2.80
Total Factor Qts 2.50
Cone Area Sd 139 cm²
Mechanical Mass Mms 9.80 g
Bl Factor Bl 6.84 Tm
Dc Resistance Re 5.5 Ohm
Inductance Le 0.19 mH at 1 kHz
Mechanical Mass Without Air Mmd 8.87 g
Mechanical Compliance Cms 0.017 mm/N

***Xmax=(Voice coil winding depth-Magnetic Gap depth)/2+ Mgnetic Gap Depth/4


EXTRA INFO

Overall Diameter 6.58″ ( 167.2mm)
Front Mount Baffle Cutout 5.79″ (147 mm)
Mounting Depth 2.20″ (56 mm)
Overall Depth 3.47″ (62.7 mm)
Net Weight 3.88 Lbs (1.76 kg)
Shipping Weight 4.32 Lbs (1.96 kg)
Carton Dimensions W x L x H 7.09″ x 7.09″ x 3.14″ (180 x 180 x 80 mm)
