6.5" MIDRANGE LOUDSPEAKER

6MR200A

In stock

6.5″ Midrange – 8 Ohm
Shallow Mount
94 dB – 200 Watts

$24.91

In stock

PRICE FOR SINGLE UNIT

SKU: 6MR200A Categories: best-sellers, Low Frequency Speakers Tags: ALTO SERIES, MIDRANGE

Features

PRV Audio’s ALTO Series were carefully crafted and voiced to reproduce a natural, smooth sound while remaining dynamic. To get the superior fidelity, a special composite cone is used to smooth frequency response and to keep the moving mass low, increasing the efficiency.

Highlights

6.5″ PRO audio Midbass speaker designed for Low Frequencies with shallow profile
200 watts RMS program power gives capability of high acoustical output with small amplifier
Impressive choice for high output home, car, and professional audio systems – 8 Ohm Impedance
Smooth response through the mid-bass and vocal range at at loudest volumes

To ensure absolute signal fidelity, a cloth sealed surround is combined with a carefully crafted Kevlar-loaded paper cone. Additionally, a vented pole piece allows heat to escape for reduced power compression.

The 6MR200A midrange speaker is the evolution of the 6MR250A, this unit was designed with the goal of producing the highest possible output from a compact design without sacrificing performance, with only 2.24″ mounting depth.

This professional midrange speaker is purpose-built to cover from 100 Hz to 6,000 Hz in three-way speakers, but also works great as a midrange in a bass guitar speaker, as well as a woofer in two-way satellite speaker concept or even as a high output car audio door speaker.

PRV 6.5″ Midrange Speaker 6MR200A 200 Watts / 8 Ohm PRO Audio Loudspeaker

Technical Details

GENERAL SPECIFICATIONS

Nominal Diameter	6″ (152 mm)
Nominal impedance	8 Ohms
Rated AES Power Handling (RMS)	100 Watts
Program Power	200 Watts
Sensitivity 2.83V at 1m	94 dB
Recommended Hi Pass Crossover* *For Full Power Handling	150 Hz 12db Per Octave Crossover
Frequency Response at -10dB	155 – 11,000 Hz
Voice Coil Diameter	1.5″ (38 mm)
Voice Coil Wire	Copper
Voice Coil Winding Depth	8.0 mm
Former Material	Kapton
Magnetic Gap Depth	5.5 mm
Frame Material	Stamped Steel

THIELE-SMALL PARAMETERS

Equivalent Volume	Vas	3.16 l
Excursion (mathematical)***	Xmax	2.62 mm
Free Air Resonance	Fs	114.1 Hz
Mechanical Factor	Qms	13.16
Electrical Factor	Qes	1.28
Total Factor	Qts	1.17
Cone Area	Sd	137 cm²
Mechanical Mass	Mms	10.1 g
Bl Factor	Bl	6.27 Tm
Dc Resistance	Re	5.5 Ohms
Inductance	Le	0.26 mH at 1 kHz
Mechanical Mass Without Air	Mmd	9.02 g
Mechanical Compliance	Cms	0.120 mm/N

***Xmax=(Voice coil winding depth-Magnetic Gap depth)/2+ Mgnetic Gap Depth/4

EXTRA INFO

Overall Diameter	6.59″ (167.5 mm)
Front Mount Baffle Cutout	5.69″ (144.5 mm)
Mounting Depth	2.24″ (57 mm)
Overall Depth	2.5″ (63.5 mm)
Net Weight	3.52 Lbs (1.60 kg)
Shipping Weight	3.79 Lbs (1.75 kg)
Carton Dimensions W x L x H	7.40″ x 7.48″ x 4.45″ (188 x 190 x 113 mm)
