Features

Add crystal clear sparkle to any speaker with PRV Audio’s TW350Ti-4 SLIM titanium bullet super tweeter! Not only does this driver look as good as it sounds and with a ultra shallow design this tweeter is easy to mount anywhere !!

The PRV Audio TW350Ti-4 SLIM Super Tweeter offers a smooth response and extremely high efficiency from mid range through high range frequencies. This tweeter a little brother of TW350Ti a Popular choice for HIGH SPL super Tweeter.

The Titanium diaphragm is on a Kapton former is light, thin and durable for long play applications. The tweeter is perfect for Pro Audio On Wheels® applications. The sharp smooth sound is perfect for applications where larger compression drivers may over power a venue.

TW350Ti-4 SLIM is designed with cast aluminum frame to ensure a quality sound and long lasting play in most any environment. Replacement Diaphragms available.

Highlights

• The low mass CCAW voice coil at 4 ohms
• Crystal Clear High Frequency Response
• High Output – 104 dB sensitivity
• Slim Design easy to Mount
• Sold in Pairs

GENERAL SPECIFICATIONS

Nominal impedance	4 Ohms
Rated AES Power Handling (RMS)	60 Watts
Program Power	120 Watts
Sensitivity 2.00V at 1m	104 dB
Recommended Hi Pass Crossover** **For Full Power Handling	5000 Hz** **12db Per Octave Crossover
Frequency Response at -10dB	4,500 – 20,000 Hz
Voice Coil Diameter	1.0” (25 mm)
Voice Coil Wire	CCAW
Voice Coil Former Material	Kapton
Diaphragm Material	Titanium
Flux Density	1.45 T
Magnet Material	Ferrite

EXTRA INFO

Overall Depth	1.67” (42.5 mm)
Mounting Depth	1.32” (33.5 mm)
Overall Diameter	3.50” (89 mm)
Cutout Diameter	2.87” (73 mm) + Terminals
Net Weight	1.14 lbs (0.51 kg)
Shipping Weight	2.64 lbs (1.20 kg)
Carton Dimensions W x L x H	8.27” x 3.78” x 1.97” (210 x 96 x 50 mm)

Replacement Diaphragm for TW350Ti-4 SLIM
