2" EXIT WAVEGUIDE

WGP14-50PR

In stock

2″ Exit Bolt-On
5″ Mount Depth
Matte White Finish

$9.91

In stock

PRICE FOR SINGLE UNIT

SKU: WGP14-50PR Categories: 2" Exit Horns / Waveguides, 2" Exit Horns for Custom Fiberglass Work, Waveguides Tag: Single Color Finish Horns

Features

The flangeless design of PRV Audio’s WGP14-50PR white exponential horn gives your high output midrange and tweeter installation a clean look. No mounting hole, made for custom fiberglass work.

With a 2″ throat and 45° x 45° dispersion, this is perfect for applications where a controlled coverage pattern is needed and space is at a premium.

2” Throat Diameter
Light weight
No Mounting Holes
Bolt-on
45° x 45° Nominal Coverage

Technical Details

GENERAL SPECIFICATIONS

Throat Diameter	2” (50.8 mm)
Mounting Type	Bolt-on
Hole Dimensions	0.31″ 8 mm
Bolt Circle	4″ 101.6 mm
Nominal Coverage
Horizontal	45°
Vertical	45°
Flare type	Exponential
Material	Plastic (ABS)
Finish / Coating	White Painting
Dimensions
Height	5.53″ (140.5 mm)
Width	5.53″ (140.5 mm)
Depth	5.0″ (127.0 mm)
Mounting Depth	5.0″ (127.0 mm)
Baffle Cutout
Diameter Circle	5.53″ (140.5 mm)
Net weight	0.40 lb (0.18 kg)
