WG175Ph
1" EXIT PHENOLIC COMPRESSION DRIVER + HORN - COMBO

WG175Ph

In stock
  • Phenolic Driver + Horn
  • 4.5″ x 4.5″ x 4.8″ Depth
  • 108 dB – 150 Watts

$24.99

In stock

PRICE FOR SINGLE UNIT

SKU: WG175Ph Category: Tags: ,

Features

The WG175Ph compression driver combo is known for excellent driver performance, reliability, and power handling as replacement and upgrade for many PA speakers that use a standard 1-3/8″-18 TPI horn. The WG175Ph is a lightweight driver that weighs just 1.92 lbs, and yet offers you outstanding response through 19kHz.

Highlights

  • Throat Diameter: 1″
  • Type: Combo
  • Nominal Impedance: 8Ω
  • Rated Power Handling: 75 Watts
  • Program Power: 150 Watts
WARNING: Cancer and Reproductive Harm – www.p65warnings.ca.gov

Technical Details

GENERAL SPECIFICATIONS

Exit Throat Diameter 1” (25.4mm)
Nominal impedance 8 Ohms
Rated Power Handling 75 Watts
Program Power 150 Watts
Sensitivity 2.83V at 1m 108 dB
Recommended Hi Pass Crossover**
**For Full Power Handling		 3000 Hz**
**12db Per Octave Crossover
Frequency Response at -10dB 1,300 – 19,000 Hz
Voice Coil Diameter 1″ (25.4 mm)
Voice Coil Wire CCAW
Voice Coil Former Material Kapton
Diaphragm Material Phenolic Resin
Flux Density 1.02 T
Magnet Material Ferrite



EXTRA INFO

Overall Depth 5.04” (128 mm)
Mounting Depth 4.76” (121 mm)
Overall Width 4.53” (115 mm)
Overall Height 4.53” (115 mm)
Net Weight 1.92 lbs (0.87 kg)
Shipping Weight 2.09 lbs (0.95 kg)
Carton Dimensions W x L x H 4.72” x 4.72” x 5.31”
(120 x 120 x 135 mm)



PRV AUDIO WG175Ph DATASHEETDownload
